Installation
Locate the ribbon cable
connector on the Circuit
Board at the rear of the
WaveReader. Using your
thumb nails and placing
them on the wings of the
small tabs, pull the slide
downward as shown
www.heartlandMicroPayments.com
5
6
7
Gently pull the white
ribbon cable out of the
connector.
Please be careful to pull
the ribbon cable from the
direction shown.
Using a small screwdriver,
remove the 2 Phillips head
machine screws from the
Circuit Board.
Make sure to keep track of
them.
