38
BACK COVER
SENSOR ASSEMBLY(BALL SENSOR)
1.
Unscrew the 4 screws from the BACK COVER.
2.
Unscrew a screw from the lower-right side of the
CABINET.
3.
Disconnect the connector from PWB HARNESS.
