2-9

Only for training and service purposes.

SPK cable

Rear Panel Assembly

Figure 2-1 (1)

Figure 2-1 (2)

2. HOW TO DISASSEMBLE THE SUBWOOFER

2-1. Rear Panel Assembly

1) Remove the 8 screws.

2) Pull out the Rear Panel Assembly and disconnect the SPK cable.
