2. PERFORMANCE
GX500 Operational Description Revision A
LG Electronics 12/143 LGE Property
7 Spurious Emissions
Conduction, Emission Status
Conduction, Emission Status
8
Bit Error Ratio
EGSM/GSM850
BER (Class II) < 2.439% @-102dBm
DCS1800/PCS1900
BER (Class II) < 2.439% @-102dBm
9
Rx Level Report accuracy
r 3 dB
10 SLR
8 r 3 dB
Frequency (Hz) Max.(dB) Min.(dB)
100 -12 /
200 0 /
300 0 -12
1,000 0 -6
2,000 4 -6
3,000 4 -6
3,400 4 -9
11
Sending Response
4,000 0 /
12 RLR 2 r 3 dB
Frequency (Hz) Max.(dB) Min.(dB)
100 -12 /
200 0 /
300 2 -7
500 * -5
1,000 0 -5
3,000 2 -5
3,400 2 -10
4,000 2
13 Receiving Response
* Mean that Adopt a straight line in between
300 Hz and 1,000 Hz to be Max. level in the
range.
14 STMR
13 r 5 dB
15 Stability Margin > 6 dB
dB to ARL (dB) Level Ratio (dB)
-35 17.5
-30 22.5
-20 30.7
-10 33.3
0 33.7
7 31.7
16
Distortion
10 25.5
