2. PERFORMANCE
GX500 Operational Description Revision A
LG Electronics 13/143 LGE Property
17
Side tone Distortion Three stage distortion < 10%
18
<Change> System frequency (26 MHz)
tolerance
d 2.5 ppm
19
<Change>32.768KHz tolerance
d 30ppm
20
Power consumption
Standby
- Normalஆd 3.8 mA(@PP5)
21
Talk Time
EGSM/Lvl 7(Battery Capacity 1500mA):450 min
EGSM/Lvl12(Battery Capacity 1500 mA):630min
22
Standby Time
Under conditions, at least 390 hours:
1. Brand new and full 1500mAh battery
2. Full charge, no receive/send and keep GSM in
idle mode.
3. Broadcast set off.
4. Signal strength display set at 3 level above.
5. Backlight of phone set off.
23
Ringer Volume
At least 65 dB under below conditions:
1. Ringer set as ringer.
2. Test distance set as 50 cm
24
Charge Current Normal charging : 680 mA
Antenna Bar Number
Power
7
>-92 dBm a
5
-97dBm a –93dBm
4
-100dBm a –98dBm
2
-103dBm a –101dBm
1
-105dBm a –104dBm
0 < –106 dBm
25
Antenna Display
Off No Service
Battery Bar Number Voltage (±0.05V)
3 3.69V~4.2V
2 3.53V~3.69V
1 3.43V~3.53V
26 Battery Indicator
0 3.35V~3.43V
3.53VĻ±0.05V (Call)
27 Low Voltage Warning
3.43VĻ±0.05V (Standby)

LG GX500 Specifications

General

Brand	LG
Model	GX500
Category	Cell Phone
Language	English
