LG HT306SF Service Manual

A
B
D
D
E
B
A
C
A50
463
A43
463
A47
463
463
A46
465
470
300
E
262
261
260
261
A44
462
250
FRONT JACK
SMPS
MAIN
A41
PN202
472
CABLE1
C
PN302
463
273
263
279
283
284
284
282
275
EXPLODED VIEWS
1. CABINET AND MAIN FRAME SECTION
NOTES) THE EXCLAMATION POINT WITHIN AN
EQUILATERAL TRIANGLE IS INTENDED
TO ALERT THE SERVICE PERSONNEL
TO THE PRESENCE OF IMPORTANT
SAFETY INFORMATION IN SERVICE
LITERATURE.
3-3 3-4

LG HT306SF Specifications

General

Audio decoders	Dolby Digital
RMS rated power	330 W
Audio output channels	5.1 channels
Weight	3500 g
Audio system	Dolby digital
Built-in HDD	No
Dimensions (WxDxH)	365 x 307 x 58.5 mm
Surround speaker weight	400 g
Apple docking compatibility	Not supported
Surround speaker dimensions (WxHxD)	97 x 110 x 80 mm
Center speaker RMS power	75 W
Satellite speakers RMS power	45 W
Video formats supported	DivX
Radio Data System (RDS)	Yes
Preset stations quantity	50
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Optical disc player type	DVD player
HDMI in	0
USB version	2.0
Karaoke	-
Product color	Black

Weight and Dimensions

Subwoofer dimensions (WxDxH)	157 x 325 x 250 mm
Center speaker dimensions (WxDxH)	97 x 80 x 110 mm
