Appendix 29
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D) Approx. 360 mm X 65 mm X 270 mm without foot
Net Weight (Approx.) 2.15 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
System
Laser Semiconductor laser, wavelength: 650 nm
Signal system Standard NTSC/ PAL color TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 80 dB
Harmonic distortion 0.5 % at 1 W
Dynamic range More than 80 dB
Bus Power Supply (USB) 5 V
0
500 mA
Amplier
Stereo mode 45 W + 45 W (3 Ω at 1 kHz)
Surround mode
Front 45 W + 45 W (3 Ω at 1 kHz)
Center 45 W (3 Ω at 1 kHz)
Surround 45 W + 45 W (3 Ω at 1 kHz)
Subwoofer 75 W (6 Ω at 80 Hz)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
DH3140S-F0_ANGAFLK_ENG_5469.indd 29 2014-06-30 2:14:17
