LG HT554TM User Manual

8
Play/Pause, Function
Press and hold down this button for
about 3 seconds then press
repeatedly to select other function.
Stop
Tuning (-/+)
Skip / Search
VSM
Selects the Dolby Pro Logic II
or Virtual sound.
Volume
Control the volume when using any function.
Open/Close
DVD/CD Disc Drawer
PORT. IN port
The PORT. In port means you can connect
an audio device to play trough the surround
sound speakers.
USB port
The USB port allows you can connect a
memory device to your DVD player.
Power
Turn the unit on and off.
MIC 1/MIC 2
Connect a microphone to MIC 1 or MIC 2 to both sockets.
Main Unit
HT554PH-A2_TRUSLL_ENG_0784 4/30/09 10:36 AM Page 8
Downloaded From TheatreSystem-Manual.com Manuals

LG HT554TM Specifications

General

Equalizer	Yes
RMS rated power	1000 W
Audio output channels	5.1 channels
Center speaker RMS power	70 W
Center speaker impedance	4 Ω
Disc types supported	DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-RW
Number of optical discs	1 discs
Optical disc player type	DVD player
Weight	3600 g
Dimensions (WxDxH)	430 x 73 x 327 mm
Power requirements	230V 50Hz
Surround speaker weight	3400 g
Surround speaker dimensions (WxHxD)	275 x 1050 x 275 mm
USB version	2.0
Product color	Black

Weight and Dimensions

Subwoofer weight	5900 g
Center speaker weight	1050 g
Subwoofer dimensions (WxDxH)	216 x 382 x 312 mm
Center speaker dimensions (WxDxH)	350 x 93 x 105 mm
