Appendix 73
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption Refer to main label on the rear panel.
Dimensions (W x H x D) Approx. 495 x 211 x 72.5 mm (19.5 x 8.3 x 2.9 inches)
Net Weight (Approx.) 4.1 kg (9.0 lbs) (With stand : 4.7 kg (10.4 lbs))
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs/Outputs
COMPOSITE 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Power output (4 Ω/ 3 Ω), (RMS), THD 10 %
Total 560 W
Front 180 W x 2
Sub-Woofer 200 W (Active)
