2. PERFORMANCE
- 14 -
2.4 Current Consumption
(Stand by Test Condition : Bluetooth off, LCD backlight off)
(Call Test Condition : Bluetooth off, LCD backlight dimming mode)
(VT Test Condition : Speaker off, LCD backlight On)
2.5 RSSI BAR
2.6 Battery BAR
Indication Standby
Bar 4 Over 3.82 ± 0.05V
Bar 4 → 3 3.81 ± 0.05V
Bar 3 → 2 3.71 ± 0.05V
Bar 2 → 1 3.66 ± 0.05V
Bar 1 → Empty 3.48 ± 0.05V
Low Voltage, 3.48 ± 0.05V (Stand-by) / 3.48 ± 0.05V (Talk)
Warning message+ Blinking [Interval : 3min(Stand-by) / 1min(Talk)]
Power Off 3.22 ± 0.05V
Stand by Voice Call VT
WCDMA
Under 3.518 mA Under 335 mA Under 569mA
(DRX=2.56) (Tx=10dBm) (Tx=10dBm)
Under 3.518 mA Under 292 mA
GSM Paging=5 period (PCL=7)
Level Change WCDMA GSM
BAR 4 → 3 -87 ± 2 dBm -91 ± 2 dBm
BAR 3 → 2 -97 ± 2 dBm -96 ± 2 dBm
BAR 2 → 1 -107 ± 2 dBm -101 ± 2 dBm
BAR 1 → 0 -112 ± 2 dBm -106 ± 2 dBm
