Level
Location
No.
Description Part Number Specification Color Remark
4 SAEY00 PCB ASSY,KEYPAD SAEY0052701 40
5 SAEB00
PCB ASSY,
KEYPAD,INSERT
SAEB0018301
5 SAEE00 PCB ASSY,KEYPAD,SMT SAEE0020501
6 SAEC00
PCB ASSY,KEYPAD,SMT
BOTTOM
SAEC0019201
7 ANT100 ANTENNA,GSM,FIXED SNGF0022201 3.0 ,-2.0 dBd,; ,internal, chip ,; ,SINGLE ,-2.0 ,50 ,3.0
7 BAT100 BATTERY,CELL,LITHIUM SBCL0001305 3 V,1 mAh,COIN ,SMT Temp.260 degree. PB-Free B/B
7 C100 CAP,CERAMIC,CHIP ECCH0000182 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP
7 C101 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C102 CAP,TANTAL,CHIP ECTH0002201 10 uF,6.3V ,M ,STD ,1608 ,R/TP
7 C103 CAP,CERAMIC,CHIP ECCH0000122 47 pF,50V,J,NP0,TC,1005,R/TP
7 C104 CAP,CERAMIC,CHIP ECCH0000179 22 nF,16V ,K ,X5R ,HD ,1005 ,R/TP
7 C105 CAP,CERAMIC,CHIP ECCH0000179 22 nF,16V ,K ,X5R ,HD ,1005 ,R/TP
7 C107 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C108 CAP,CERAMIC,CHIP ECCH0000110 10 pF,50V,D,NP0,TC,1005,R/TP
7 C111 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7 C112 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7 C113 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 C114 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C115 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7 C116 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7 C117 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 C118 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C119 CAP,CHIP,MAKER ECZH0001421 2.2 uF,6.3V ,K ,X5R ,HD ,1608 ,R/TP
7 C120 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 CN100
CONNECTOR,
BOARD TO BOARD
ENBY0041101
40 PIN,0.5 mm,ETC , , ,; , ,0.50MM ,STRAIGHT ,MALE
,SMD ,R/TP , ,
7 D100 DIODE,TVS EDTY0008607 SC70-6L ,6 V,200 W,R/TP ,PB-FREE
7 M100 MODULE,ETC SMZY0014801 BLUETOOTH RF MODULE(5.0x4.2x1.4), RFMD Chipset
7 MIC100 MICROPHONE SUMY0010602
UNIT ,-42 dB,6.15*3.76*1.25 ,Silicon mic , ,-42 ,300
,OMNI ,[empty] ,6.15*3.76*1.25 ,SMD
7 R100 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
7 R101 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R102 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
