LG KU950 - Page 196

10. EXPLODED VIEW & REPLACEMENT PART LIST
- 197 -
Level
Location
No.
Description Part Number Specification Color Remark
4 MPBZ03 PAD MPBZ0147901 COMPLEX, (empty), , , , , 54
4 MSDC00 SPRING,LOCKER MSDC0008301 72
4 MTAA01 TAPE,DECO MTAA0123901 COMPLEX, (empty), , , , , 63
4 MTAA02 TAPE,DECO MTAA0124001 COMPLEX, (empty), , , , , 65
4 MTAB01 TAPE,PROTECTION MTAB0138901 COMPLEX, (empty), , , , ,
4 MTAC00 TAPE,SHIELD MTAC0042301 COMPLEX, (empty), , , , , 58
4 MTAE00 TAPE,WINDOW(SUB) MTAE0028901 COMPLEX, (empty), , , , , 69
4 MTAZ00 TAPE MTAZ0148301 COMPLEX, (empty), , , , , 47
4 MWAE00 WINDOW,CAMERA MWAE0020701 CUTTING, PMMA MR 200, , , , ,
4 MWAH00 WINDOW,FLASH MWAH0006901 MOLD, PC LEXAN 141R, , , , , 81
4 SUSY00 SPEAKER SUSY0022601 PIN ,8 ohm,90 dB,17 mm,Spring Contact Type 48
3 GMEY00 SCREW MACHINE,BIND GMEY0011201 1.4 mm,3 mm,MSWR3(BK) ,N ,+ ,NYLOK 22,74
3 MCCH01 CAP,SCREW MCCH0091001 COMPLEX, (empty), , , , , Silver 77
3 MCCH02 CAP,SCREW MCCH0091101 COMPLEX, (empty), , , , , Silver 76
3 MLAK00 LABEL,MODEL MLAK0010701 G7200 (CE0889) White 75
3 SAFY00 PCB ASSY,MAIN SAFY0178401 43
4 SAFB00 PCB ASSY,MAIN,INSERT SAFB0067701
5 ACMY00 CAMERA ASSY ACMY0005301 45
6 ACKA00 CAN ASSY,SHIELD ACKA0000801 85
7 MCBA00 CAN,SHIELD MCBA0011801 PRESS, Bs, , , , ,
7 MTAZ00 TAPE MTAZ0170001 COMPLEX, (empty), , , , ,
6 MBFP00 BRACKET,CAMERA MBFP0006401 MOLD, PC LUPOY SC-1004A, , , , , 89
6 MCBA00 CAN,SHIELD MCBA0011901 PRESS, Bs, , , , , 88
6 MGAZ00 GASKET MGAZ0050001 COMPLEX, (empty), , , , , 92
6 MGAZ01 GASKET MGAZ0050101 COMPLEX, (empty), , , , , 93
6 MTAC00 TAPE,SHIELD MTAC0043401 COMPLEX, (empty), , , , , 91
6 MTAZ00 TAPE MTAZ0148601 COMPLEX, (empty), , , , , 90
5 ADCA00 DOME ASSY,METAL ADCA0057401 39
5 MFEA00 FRAME,SHIELD MFEA0011801 MOLD, PC LUPOY SC-1004A, , , , , 42
