LG KU950 - Page 215

10. EXPLODED VIEW & REPLACEMENT PART LIST
- 216 -
Level
Location
No.
Description Part Number Specification Color Remark
6 L109 INDUCTOR,CHIP ELCH0005010 1.8 nH,S ,1005 ,R/TP ,
6 L110 INDUCTOR,CHIP ELCH0003813 47 nH,J ,1005 ,R/TP ,COIL TYPE
6 L111 INDUCTOR,CHIP ELCH0003824 10 nH,J ,1005 ,R/TP ,chip inductor,PBFREE
6 L112 INDUCTOR,CHIP ELCH0005013 4.7 nH,S ,1005 ,R/TP ,
6 L113 INDUCTOR,CHIP ELCH0001402 18 nH,J ,1005 ,R/TP ,Pb Free
6 L114 INDUCTOR,CHIP ELCH0005013 4.7 nH,S ,1005 ,R/TP ,
6 L115 INDUCTOR,CHIP ELCH0005016 8.2 nH,J ,1005 ,R/TP ,
6 L116 INDUCTOR,CHIP ELCH0001032 18 nH,J ,1005 ,R/TP ,PBFREE
6 L117 INDUCTOR,CHIP ELCH0005016 8.2 nH,J ,1005 ,R/TP ,
6 L118 INDUCTOR,CHIP ELCH0005012 3.9 nH,S ,1005 ,R/TP ,
6 L125 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6 LD900 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD901 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD902 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD904 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD905 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD906 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD907 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD908 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD909 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 LD910 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
6 R102 RES,CHIP,MAKER ERHZ0000286 4700 ohm,1/16W ,F ,1005 ,R/TP
6 R103 RES,CHIP ERHY0000253 4.3K ohm,1/16W,J,1005,R/TP
6 R104 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
6 R105 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R106 RES,CHIP ERHY0011601 11 Kohm,1/16W ,F ,1005 ,R/TP
6 R107 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R108 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP
6 R109 RES,CHIP,MAKER ERHZ0000512 82 ohm,1/16W ,J ,1005 ,R/TP
6 R110 RES,CHIP,MAKER ERHZ0000267 3300 ohm,1/16W ,F ,1005 ,R/TP
6 R111 RES,CHIP,MAKER ERHZ0000307 6200 ohm,1/16W ,F ,1005 ,R/TP
6 R112 RES,CHIP,MAKER ERHZ0000419 15 ohm,1/16W ,J ,1005 ,R/TP
6 R113 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
6 R114 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R115 RES,CHIP,MAKER ERHZ0000531 270 ohm,1/16W ,J ,1005 ,R/TP
6 R116 RES,CHIP ERHY0003501 220 ohm,1/16W ,J ,1005 ,R/TP
6 R117 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
