2.5. SUB_LCD Bottom Side
Reference Description Reference Description
Vibrator Vibrator PAD CN101
Main To LCD_SUB B To B
Connector
Receiver Receiver PAD CN100
LCD_SUB To LCD B To B
Connector
3. TECHNICAL BRIEF
- 78 -
CN101
Vibrator PAD
Receiver PAD
CN100
