LG LAB-M7500 User Manual

Connections
10
+
+
+
+
+
+
+
IGNITION
SWITCH
DIMMER SWITCH (OPTIONAL)
POWER
ANTENNA
POWER AMPLIFIER
(optional)
6 REMOTE ON (BLUE/WHITE STRIPE)
CONTROL
RELAY
1
GND (BLACK)
5
PWR ANT (BLUE)
3
TO IGNITION (RED)
2
DIMMER (ORANGE) :
OPTIONAL
15A
4
FILTER BOX
E
A
B
C
BATTERY
CD CHANGER
(optional)
D
OPTIONAL
TO BATTERY (YELLOW)
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
VIOLET (FL +)
VIOLET/ BLACK STRIPE (FL -)
GRAY (FR +)
GRAY/ BLACK STRIPE (FR -)
GREEN (RL +)
GREEN/ BLACK STRIPE (RL -)
BROWN (RR +)
BROWN/BLACK STRIPE (RR -)
Connecting to the Car
Before connecting, make sure that the ignition switch is set to OFF, and remove the battery terminal to avoid short circuits.
not supplied
