ASSEMBLING AND PREPARING
Preparing Built-in Camera
1 Pull up the slide at the back of the TV.
Slide
Angle Adjustment
Lever
NOTE
y
Remove the protective film before using
the built-in camera.
2 You can adjust the angle of the camera with
the angle adjustment lever on the back of the
built-in camera.
5
7
Lever
Lens
<Side View>
3 Push down the built-in camera when you are
not using it.
Name of Parts of Built-in Camera
Camera Lens
Microphones
Protective Film
Checking the Camera’s Shooting
Range
1 Press the
(Smarthome) button on the
remote control to display the Launcher menu.
2 Select CAMERA and then press the
Wheel(OK) button.
NOTE
y
The optimal distance from the camera
to use the motion recognition function is
between 1.5 m and 4.5 m.
