1. This dishwasher is designed to fit to the size shown as below.
2. Select a location as close to sink as possible for easy connections to water and drain lines.
3. The dishwasher should not be installed more than 3 meters from sink for proper drainage.
4. If dishwasher is to be installed in corner, minimum 5 cm of space is required between the washer and an
adjacent cabinet or a wall.
Ensure the floor under the dishwasher is at the same level as the rest of the room to allow for any
service requirements.
Step1: Prepare Cupboard opening
If bare chipboard is adjacent to or above
the dishwasher, it should be sealed with
a waterproofing paint or sealant to prevent
swelling due to steam.
Cut out for hoses and electrical
cables on either side.
( approx.. 100 X 75 )
Cupboard Opening Dimension
( mm )
9. INSTALLATION INSTRUCTION
