Speci cations
Item Sepecification
Video
Video Format NTSC/PAL (Selectable)
Input 4 x Composite 1.0Vp-p, 75Ω BNC
Output
Loop Through 4 x Composite 1.0Vp-p, 75Ω BNC
Composite 1 x Composite 1.0Vp-p, 75Ω BNC
VGA 1 x RGB, 15-pin D-sub
Spot 1 x Composite 1.0Vp-p, 75Ω BNC
Audio
Input 4 x Mono, RCA Line in
Output 1 x Mono, 0dB RCA
Alarm
Input 4 (NC/NO selectable)
Output 1 (NC/NO selectable)
Alarm Notification to e-mail Yes
Recording
Frame Rate (/Sec)
NTSC
Up to 120 IPS @ 352x240, Up to 60 IPS @ 704x240, Up to
30 IPS @ 704x480
PAL
Up to 100 IPS @ 352x288, Up to 50 IPS @ 704x288, Up to
25 IPS @ 704x576
Quality Level 5 Levels
Recording Mode Continuous, Alarm, Motion, Instant
Schedule Recording Yes
Event Partition Recording Yes
Pre-Event Recording Time Up to 60 sec
Search
Playback Function FF, FB, Frame Advance
Playback Speed
x1, x2, x4, x8, x16
-x1, -x2, -x4, -x8, -x16
Search Mode Date/Time, Event (Motion, Alarm), Boorkmark
Instant Playback Yes
Display
&
User I/F
Screen Division Mode 1, 4
OSD type GUI
User Interface Mouse, IR Remote, Keyboard Controller (LKD1000)
Storage
Interanl HDD
Interface Type SATA
Max Capacity
1TB (Up to 2 HDDs) – LE2104 series
500GB (Up to 1 HDD) – LE2104D series
Internal ODD Yes (LE2104D model Only)
Backup /
Export
Backup/Export Device Interface 3 x USB 2.0, Network
Schedule Backup (Automatic Backup) Yes
Backup Time Estimation Yes
Backup/Export File Format AVI, Native DVR Format
Serial I/F
PTZ Control
Interface 2 x Half-duplex RS-485
Control
Function
Pan, Tilt, Zoom, Focus, Iris, Preset, Tour, Camera OSD Control
RS232 Interface 1 x RS-232C, 9-pin D-sub (Consol)
RS485 Interface 2 x Terminal block (PTZ or Remtote Control Keyboard)
