13. EXPLODED VIEW & REPLACEMENT PART LIST
- 177 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Note: This Chapterisused for reference,Part order is ordered
by SBOM standard on GCSC
Level LocationNo. Description PartNumber Spec Remark
1 AGQ000000 Phone Assembly AGQ87205601 LGE410.AAREBK BK:BLACK BLACK -
2 MEZ002100 Label,Approval MLAA0062303 COMPLEX KB770 DEUBK ZZ:Without Color -
2 ACQ100400
Cover
Assembly,EMS
ACQ86704601 LGE410.AAREBK BK:BLACK BLACK -
3 ACQ003400
Cover
Assembly,Bar
ACQ86553802 LGE410.AAREBK ZZ:Without Color -
4 MEZ000000 Label MLAZ0038301
COMPLEX LG-VX6000 ZZ:Without Color PID Label
4 Array PRINTING,
4 MJN107400 Tape,USP Film MJN68549402 COMPLEX LGE410.AAREBK ZZ:Without Color -
4 MJN061101 Tape,Protect MJN68537301
COMPLEX LGE410G.ATCLBK ZZ:Without Color
E410 Tape Protection2
4 MJN01 Tape MJN68470301 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
4 MJN02 Tape,Window MJN68470201 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
13.2 Replacement Parts
<Mechanic component>
4 MDS00 Gasket MDS64271901 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
4 ACQ00
Cover
Assembly,Front
ACQ86553901 LGE410G.ATCLBK ZZ:Without Color -
5 MJN04 Tape,Window MJN68470101 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
5 MDJ000000 Filter MDJ63724501 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
5 MCQ000000 Damper MCQ67386601 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
5 MJN03 Tape,Window MJN68509301 COMPLEX LGE410G.ATCLBK ZZ:Without Color -
5 ACQ033200
Cover Assembly
Front(Sub)
ACQ86554001 LGE410G.ATCLBK ZZ:Without Color -
