4. TROUBLE SHOOTING
- 37 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Check TP1
VCC of TCXO
VCC ≥ 2.8V
Check PM8029
No
Yes
Check TP2
2.4V ≥ Voltage ≥ 0.4V
Check MSM7225A
No
Yes
Check TP3
19.2 MHz Signal
Check soldering and components
No
Yes
TCXO is OK
