4. TROUBLE SHOOTING
- 42 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4.5.1 Checking TCXO Block
Refer to 4.3
4.5.2 Checking Tx Module Block
Refer to 4.4
4.5.3 Checking RF TX Level
Test Point (TX Level)
TP4 TP3
TP2
TP1
