4. TROUBLE SHOOTING
- 50 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Set the phone Rx is On
Check bias block soldering
No
Yes
Change the board
Check TP1 Signal exist?
Check RF Switch (M/S)
No
Yes
Check TP2 Signal exist?
Check TX Module Refer 1.4
No
Yes
Check TP3 Signal exist?
Check Duplexer
No
Yes
Check TP4 Signal exist?
DNI  SKIP
No
Yes
Check TP5 Signal exist?
Check RTR6285 and Rx SAW lter
No
Yes
Check BIAS over 2.1 V?
