4. TROUBLE SHOOTING
- 71 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
TP1
TP2
VREG_MSME_1.8V
VREG_MSMC2_1.1V
VREG_MSMC1_1.1V
VREG_MSMA2_1.2V
VREG_P3_2.85V
VREG_TCXO_2.85V
VREG_MSMA1_2.6V
