GeneralCD/DVDVideo
Amplifier
Speakers
Tuner
FM
❋
This model complies with the above specifications.
❋
Design and specifications are subject to change without notice.
❋
This model may not be compatible with features and/or specifications that may be added in the future.
Specifications
Power supply Refer to main label
Power consumption Refer to main label
Mass 5.6 kg
External dimensions (W x H x D) 430 x 93.3 x 351.6 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Signal system NTSC 525/60
Frequency response (audio) 150 Hz to 18 kHz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, NOP -6 dB, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 70 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
Video input 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 2
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 2
Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response 150 - 8000 Hz
Tuning Range 520 - 1720 kHz
Intermediate Frequency 450 kHz
Stereo mode 155W + 155W (4Ω at 1 kHz, THD ±10 %)
Surround mode Front: 155W + 155W (THD ±10 %)
Centre*: 155W
Surround*: 155W + 155W (4Ω at 1 kHz, THD ±10 %)
Subwoofer*: 225W ( 3Ω at 30 Hz, THD ±10 %)
Inputs AUX, AUDIO IN, OPTICAL IN, COAXIAL IN
Outputs MONITOR OUT, HDMI OUT, COMPONENT VIDEO OUT
Front/Rear Speaker Center speaker Passive Subwoofer
(SH92TB-S) (SH92TB-C) (SH92TB-W)
Type 2 Way 3 Speaker 2 Way 3 Speaker 1 Way 1 Speaker
Impedance 4 Ω 4 Ω 3 Ω
Frequency Response 80 - 18000 Hz 80 -18000 Hz 40 - 1500 Hz
Sound Pressure Level 83 dB/W (1m) 83 dB/W (1m) 82 dB/W (1m)
Rated Input Power 155 W 155 W 225 W
Max. Input Power 310 W 310 W 450 W
Net Dimensions (W x H x D)
280 x 1201 x 280 mm 450 x 161 x 102 mm 258 x 440 x 401 mm
Net Weight 4.4 kg 1.8 kg 6.8 kg
(*
Depending on the sound mode
settings and the source, there
may be no sound output.)
AM
