20 MPS Variable Multi Split System(50Hz, R410A)
5. Specifications
Notes: 1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 27°C(80.6°F) DB /19°C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
- Outdoor Temperature 35°C(95°F) DB /24°C(75.2°F) WB - Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Interconnecting Piping Length 7.5m - Interconnecting Piping Length 7.5 m
- Level Difference of Zero. - Level Difference of Zero.
2. Capacities are Net Capacities.
3.
★
: See the page "Combination Table"
4. Due to our policy of innovation some specifications may be changed without notification.
Model
Cooling Capacity ★ kcal/hr
W
Btu/hr
Heating Capacity ★ kcal/hr
W
Btu/hr
Input ★ Cooling/Heating W
Running Current ★ Cooling/Heating A
Starting Current Cooling/Heating A
Power Supply Ø,V,Hz
Power Factor %
Compressor A Locked Rotor Amp. A
Type
Quantity No
Model
Maker
Capacity kcal/hr(Btu/hr)
Motor Type
Motor Input W
Oil Type
Oil Charge cc
O.L.P Type(model name)
Compressor B Locked Rotor Amp. A
Type
Quantity No
Model
Maker
Capacity kcal/hr(Btu/hr)
Motor Type
Motor Input W
Oil Type
Oil Charge cc
O.L.P Type(model name)
Refrigerant Charge g(oz), type
Type
Control
Coil Tube Size (OD) inch(mm)
Fins per inch
No. of Rows & Column/No.
Fan Motor Output W
Model
No. of Poles
Input W
Running Current A
Capacitor µF/Vac
Fan Type
No. Used / Diameter EA/inch(mm)
Discharge Side / Top
Speed rpm
Air Circulation CMM(CFM)
Noise Level(Sound Press,1m) dBA
Piping Connection Liquid inch(mm)
Gas inch(mm)
Drain(ID Ø)mm
Dimensions (W*H*D) inch(mm)
Net Weight kg(lbs)
Power Supply Cable No.* mm
2
Interunit Cable No.* mm
2
Max. Interunit Piping Length
Total of Each Room m
For One Room m
Max. Installation Indoor Unit~Outdoor Unit m
Height Difference Indoor Unit~Indoor Unit m
Packing Dimension (W*H*D) inch(mm)
Stuffing Quantity With(Without) S/Parts 20/40ft
2369~3629 1764~4536 2016~5292 2268~7560
2755~4220 2051~5275 2345~6154 2638~8787
9400~14400 7000~18000 8000~21000 9000~30000
2520~3679 2268~4990 2268~5292 2520~8317
2931~4279 2638~5803 2638~6154 2931~9666
10000~14600 9000~19800 9000~21000 10000~33000
1350~1450/1300~1500
780~1900 / 1200~1900 880~2100 / 1350~2200 1100~3250 / 1310~3360
6.1~6.6/6.0~7.0 3.5~8.5 / 5.5~8.5 4.0~9.4 / 6.0~9.8 4.8~15 / 6.0~15.5
-- --
1,220-240,50 1,220-240,50 1,220-240,50 1,220-240,50
-- --
37 24 25.2 35.5
Rotary Rotary Rotary Rotary
11 11
GJ176PAA 5KS140DAD21 5KS150EAB21 5KS225DKSM681
LG. Electric Matsushita Electric Matsushita Electric Matsushita Electric
3654(14500) at 50Hz & 240V 2932(11635) at 50Hz & 240V 3130(12420) at 50Hz & 240V 4901(19450) at 50Hz & 240V
Permanent split capacitor Permanent split capacitor Permanent split capacitor Permanent split capacitor
1526 1290 1290 2175
FVS68D(PVE) FV50S(PVE) FV50S(PVE) FV50S(PVE)
500 670 670 670
Internal MRA98781-9090 MRA99150-9090 Internal
- 17.2 20.3 25.2
- Rotary Rotary Rotary
-1 11
- 5PS102EAC21 5PS112EBB21 5KS150DKSM564
- Matsushita Electric Matsushita Electric Matsushita Electric
-
2076(8240) at 50Hz & 240V 2253(8940) at 50Hz & 240V 3181(12625) at 50Hz & 240V
- Permanent split capacitor Permanent split capacitor Permanent split capacitor
- 865 975 1320
- FV50S(PVE) FV50S(PVE) FV50S(PVE)
- 350 350 670
- MRA99901-9090 MRA99282-9090 MRA99150-9090
1100(38.8) at 7.5m 1350(47.62) at 7.5m 1500(52.91) at 7.5m 2500(88.2) at 7.5m
R410A R410A R410A R-410A
Capiilary Tube L.E.V L.E.V L.E.V
0.276(7.0) 0.276(7.0) 0.276(7.0) 0.276(7.0)
18 18 18 18
2R,24C 2R,28C 2R,28C 2R,48C
27 67.2 67.2 41
AMR036E1 IC-28640LG28J IC-28640LG28J IC-9625LGSY
46 66
79 120 120 80
0.35 1.4 1.4 0.35
1.5/400 6/370 6/370 2/370
Propeller Propeller Propeller Propeller
1/15.25(387.6) 1/18.1(460) 1/18.1(460) 2/15.7(400)
Side Discharge Side Discharge Side Discharge Side Discharge
680 850 850 880 / 710
40(1412) 53(1872) 53(1872) 63(2225)
52 53 53 54/51
1/4(6.35)*2EA 1/4(6.35)*2EA 1/4(6.35)*3EA 1/4(6.35)*4EA
3/8(9.52)*2EA 3/8(9.52)*2EA 3/8(9.52)*3EA 3/8(9.52)*4EA
-- -32
31.5*21.8*10.3 (801 * 555 * 262) 34.3*25.8*12.6 (870*655*320) 34.3*25.8*12.6 (870*655*320) 34.3*41.7*12.6 (870*1060*320)
48(106) 64(141) 64(141) 80(176)
3*2.1(Includes earth) 3*3.5(Includes earth) 3*3.5(Includes earth) 3*4.5(Includes earth)
4*0.75(Includes earth) 4*0.75(Includes earth) 4*0.75(Includes earth) 4*0.75(Includes earth)
30 30 45 60
15 15 15 15
7.5 7.5 7.5 7.5
7.5 7.5 7.5 7.5
37.8*24.0*15.1 (960*610*384) 40.1*28.1*17.3 (1020*715*440) 40.1*28.1*17.3 (1020*715*440) 41.1*44.9*17.3 (1045*1140*440)
108/222 (108/222) 80/170(81/171) 80/170(81/171) (51/111)
A2UH146FA0 A2UH186FA0 A3UH216FA0 A4UH306FA0
Heat Pump
To Next Page
