LG LM50 2004-E1 - Dimensional Drawings

2004 Product Data 27
7. Dimensional Drawings
AMNC-LQ/LR/LT, AMNH-LQ/LR/LT
W
824
900
1090
H
260
285
314
D
155
156
172
Model
AMNC/H076LQL0
AMNC/H096LQL0
AMNC/H126LRL0
AMNC/H186LTL0
AMNC/H246LTL0
(unit : mm)
7.1 Indoor Units
Installation plate
D
H
W
More than 5cm
More than
5cm
More than 2.3m
More than
5cm
Ø 12.7Ø 6.35
18, 24k
Ø 9.52Ø 6.35
7, 9, 12k
GasLiquidModel
1. Pipe Specification(mm)
Note:
4020400
SR(12k)
0
12
D
0
12
BCA
210105
ST(18/24k)
8075SQ(7/9k)
Distance(mm)
CHASSIS
(Grade)
Installation plate
Ø70mm
Left rear piping Right rear piping
C
D
B
A
Ø70mm
