66 MPS Variable Multi Split System(50Hz, R410A)
13. Sound Levels
Overall
Sound Pressure Level
AMNC/H076LQL0 AMNC/H096LQL0 AMNC/H126LRL0
AMNC/H186LTL0 AMNC/H246LTL0
Model
AMNC/H076LQL0
AMNC/H096LQL0
AMNC/H126LRL0
Sound Levels(dBA)
H M L
34
35
38
31
32
36
28
30
34
Model
AMNC/H186LTL0
AMNC/H246LTL0
Sound Levels(dBA)
H M L
42
46
38
40
35
38
0.8m
1m
Microphone
Notes:
- Sound measured at 1m away from the center of the unit.
- Data is valid at free field condition.
- Data is valid at nominal operation condition.
- Reference accoustic pressure 0dB=20µPa.
- Sound level will vary depending on a range of factors such as
the construction(acoustic absorption coefficient) of particular
room in which the equipment is installed.
- The operating conditions are assumed to be standard(KS conditions).
10
20
30
40
50
60
70
80
90
NC- 15
NC- 70
NC- 65
NC- 60
NC- 55
NC- 50
NC- 45
NC- 40
NC- 35
NC- 30
NC- 25
NC- 20
Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
63 125 250 500 1000 2000 4000 8000
10
20
30
40
50
60
70
80
90
NC- 15
NC- 70
NC- 65
NC- 60
NC- 55
NC- 50
NC- 45
NC- 40
NC- 35
NC- 30
NC- 25
NC- 20
Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
63 125 250 500 1000 2000 4000 8000
10
20
30
40
50
60
70
80
90
NC- 15
NC- 70
NC- 65
NC- 60
NC- 55
NC- 50
NC- 45
NC- 40
NC- 35
NC- 30
NC- 25
NC- 20
Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
63 125 250 500 1000 2000 4000 8000
10
20
30
40
50
60
70
80
90
NC- 15
NC- 70
NC- 65
NC- 60
NC- 55
NC- 50
NC- 45
NC- 40
NC- 35
NC- 30
NC- 25
NC- 20
Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
63 125 250 500 1000 2000 4000 8000
10
20
30
40
50
60
70
80
90
NC- 15
NC- 70
NC- 65
NC- 60
NC- 55
NC- 50
NC- 45
NC- 40
NC- 35
NC- 30
NC- 25
NC- 20
Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
63 125 250 500 1000 2000 4000 8000
13.1 Indoor Unit
Wall Mounted
