Cooling
6.1.4 A4UC306FA0
22 MPS Variable Multi Split System(50Hz, R410A)
6. Combination Table
Combination(k Btu)
Capacity (Btu/h)
Cooling
Unit-A Unit-B Unit-C Unit-D Total
Input
(W)
Current
(A)
EER
(Btu/h.W)
ABCDTotal
Operation
7 7 9000 9000 1200 5.2 7.5
9 9 10000 10000 1200 5.2 8.3
1 UNIT 12 12 12000 12000 1200 5.2 10.0
18 18 18000 18000 1950 9.1 9.2
24 24 24000 24000 3250 15.0 7.4
7 7 14 8000 8000 16000 1950 9.1 8.2
7 9 16 7500 9500 17000 1950 9.1 8.7
7 12 19 7000 12000 19000 1950 9.1 9.7
7 18 25 9000 19000 28000 3250 15.0 8.6
7 24 31 7000 23000 30000 3250 15.0 9.2
2 UNIT 9 9 18 9000 9000 18000 1950 9.1 9.2
9 12 21 11000 14000 25000 3250 15.0 7.7
9 18 27 10000 18000 28000 3250 15.0 8.6
9 24 33 8000 22000 30000 3250 15.0 9.2
12 12 24 13000 13000 26000 3250 15.0 8.0
12 18 30 12000 18000 30000 3250 15.0 9.2
7 7 7 21 9000 9000 9000 27000 3250 15.0 8.3
7 7 9 23 9000 9000 11000 29000 3250 15.0 8.9
7 7 12 26 8000 8000 12000 28000 3250 15.0 8.6
7 7 18 32 6500 6500 17000 30000 3250 15.0 9.2
3 UNIT 7 9 9 25 9000 10000 10000 29000 3250 15.0 8.9
7 9 12 28 7500 9500 12000 29000 3250 15.0 8.9
7 12 12 31 7000 11500 11500 30000 3250 15.0 9.2
9 9 9 27 10000 10000 10000 30000 3250 15.0 9.2
9 9 12 30 9000 9000 12000 30000 3250 15.0 9.2
9 12 12 33 8000 11000 11000 30000 3250 15.0 9.2
7 7 7 7 28 7500 7500 7500 7500 30000 3250 15.0 9.2
4 UNIT
7 7 7 9 30 7000 7000 7000 9000 30000 3250 15.0 9.2
7 7 7 12 33 6500 6500 6500 10500 30000 3250 15.0 9.2
7 7 9 9 32 6500 6500 8500 8500 30000 3250 15.0 9.2
