32 MPS Variable Multi Split System(50Hz, R410A)
7. Dimensional Drawings
A4UC306FA0, A4UH306FA0
76.5
4-holes for anchor bolts
50
5050505050
32064
160160 550
1060
360 340 320
1030
870
4
2
3
1
Number Name Descripition
1 Liquid side service valve(mm) Ø6.35
2 Gas side service valve(mm) Ø9.52
3 Air discharge grill
4 Control Cover
