4.4. Input tool option.
Adjust tool option refer to the BOM.
▪ Tool Option Input : PCBA Check Process
▪ Area Option Input : Set Assembly Process
*** Tool Option table
MODEL 32LS5700
(AUO)
32LS5700 42LS5700 47LS5700 55LS5700
Tool Option1 4452 356 358 359 361
Tool Option2 9557 9557 9557 9557 9557
Tool Option3 845 845 845 845 845
Tool Option4 12910 12910 12908 12908 12908
Tool Option5 4765 21021 21021 21021 21021
Tool Option6 1321 1321 1321 1321 1321
Tool Option7 4651 555 4907 4395 4395
MODEL 32LM6200 37LM6200 42LM6200 47LM6200 55LM6200 65LM6200
(AUO)
Tool Option1 116 117 118 119 121 36987
Tool Option2 9557 9557 9557 9557 9557 9557
Tool Option3 17229 17229 17229 17229 17229 17229
Tool Option4 12910 12910 12908 12908 12908 12910
Tool Option5 23069 23069 23069 23069 23069 6685
Tool Option6 1321 1321 1321 1321 1321 1321
Tool Option7 555 555 4907 4395 4395 12311
MODEL 32LM6400 42LM6400 47LM6400 55LM6400 42LM6600 42LM6690 47LM6690
Tool Option1 33156 33158 33159 33161 32934 32934 32935
Tool Option2 42325 42325 42325 42325 42325 42325 42325
Tool Option3 17229 17229 17229 17229 17229 17229 17229
Tool Option4 12911 12909 12909 12909 12909 12909 12909
Tool Option5 23191 23191 23191 23191 23191 23191 23191
Tool Option6 1321 1321 1321 1321 1321 1321 1321
Tool Option7 1963 6059 6059 6059 6059 6059 6059
MODEL 42LM6700 47LM6700 55LM6700 42LM7600 47LM7600 55LM7600 42LM7600
Tool Option1 32950 32951 32953 32966 32967 32969 32966
Tool Option2 42325 42325 42325 42325 42325 42325 42325
Tool Option3 17229 17229 17229 17229 17229 17229 17229
Tool Option4 12909 12909 12909 12909 12909 12909 12909
Tool Option5 23191 23191 23191 23191 23191 23191 23191
Tool Option6 1321 1321 1321 1321 1321 1321 1321
Tool Option7 6059 6059 6059 13355 13611 13611 13355
After Input Tool Option and AC off
Before PCBA check, you have to change the Tool option and
have to AC off/on (Plug out and in)
(If missing this process, set can operate abnormally)
4.4.1. Profile
Must be changed the option value because being different with
some setting value depend on module maker, inch and market
4.4.2. Equipment
Adjustment remote control
4.4.3. Adjustment method
The input methods are same as other chassis.(Use ADJ Key
on the Adjust Remocon.)
(If not changed the option, the input menu can differ the model
spec.)
Refer to Job Expression of each main chassis ass’y
(EBTxxxxxxxx) for Option value
Caution : Don’t Press “IN-STOP” key after completing the
function inspection.
4.5. EDID D/L method
Recommend that don’t connect HDMI and RGB(D-SUB) cable
when downloading the EDID.
If not possible, recommend that connect the MSPG equipment.
There are two methods of downloading the edid data
4.5.1. 1st Method
EDID datas are automatically downloaded when adjusting the
Tool Options.
Automatically downloaded when pushing the enter key after
adjusting the tool option5.
It takes about 2seconds
4.5.2. 2nd Method
● Caution : Must be checked that the tool option is right or not.
If tool option is wrong, hdmi edid data could not be
downloaded well.
1) Press the ADJ key
2) Move to the 10. EDID D/L and Press the right direction
key(►)
3) Press the right direction key(►) at Start.
4) After about a few seconds, appear “Waiting..” => “OK”, then
compele.
4.5.3. RS-232C command Method
1) Command : AE 00 10
● Caution : Don’t connect HDMI and RGB(D-SUB) cable when
downloading the EDID.
If the cables are connected, Downloading of edid
could be failed
