4. General Specification
No Item Specication Remark
1. Display Screen Device 32” wide Color Display Module
37” wide Color Display Module
42” wide Color Display Module
47” wide Color Display Module
55” wide Color Display Module
60” wide Color Display Module
65” wide Color Display Module
Resolution: 1920*1080
Resolution: 1920*1080
Resolution: 1920*1080
Resolution: 1920*1080
Resolution: 1920*1080
Resolution: 1920*1080
Resolution: 1920*1080
2. Aspect Ratio 16:9 All
3. LCD Module 32” TFT WUXGA LCD
37” TFT WUXGA LCD
42” TFT WUXGA LCD
47” TFT WUXGA LCD
55” TFT WUXGA LCD
60” TFT WUXGA LCD
65” TFT WUXGA LCD
4. Operating Environment 1) Temp. : 0 ~ 40 deg LGE SPEC
2) Humidity : 0 ~ 85%
5. Storage Environment 1) Temp. : -20 ~ 60 deg
2) Humidity : 10 ~ 90%
6. Input Voltage AC100 ~ 240V, 50/60Hz
7. Power Consumption(Max) =
LCD(Module) + Backlight(LED)
FHD 60Hz
Edge LED
32” 50 W Normal : T320HVN01.0 [32LS5700-DA/B]
Normal : LC320EUN-SEM1 [32LS5700-DA/B]
42” 70 W Normal : LC420EUE-SEM1 [42LS5700-DA/B]
47” 85 W Normal : LC470EUE-SEM1 [47LS5700-DA/B]
55” W Normal : LC550EUE-SEM1 [55LS5700-DA/B]
FHD
T120Hz
Edge LED
32” 45 W FPR : LC320EUN-SEF2 [32LM6200-DA]
50 W FPR : LC320EUA-KEF1 [32LM6400-DA]
37” 50 W FPR : LC370EUN-SEF2 [37LM6200-DA]
42” 60 W FPR : LC420EUE-SEF1 [42LM6200-DA]
60 W FPR : LC420EUG-KEF1 [42LM6600-DA]
FPR : LC420EUG-KEF1 [42LM6690-DA]
FPR : LC420EUG-KEF1 [42LM6700-DC]
FPR : LC420EUG-KEF1 [42LM6400-DJ]
47” 90 W FPR : LC470EUE-SEF1 [47LM6200-DA]
70 W FPR : LC470EUG-KEF1 [47LM6400-DJ]
FPR : LC470EUG-KEF1 [47LM6690-DC]
FPR : LC470EUG-KEF1 [47LM6700-DA]
55” 115 W FPR : LC550EUE-SEF1 [55LM6200-DA]
70 W FPR : LC550EUG-KEF1 [55LM6400-DJ]
FPR : LC550EUG-KEF1 [55LM6700-DA]
FHD
M120Hz
Edge LED
65” 230 W FPR : T645HB01 V0 [65LM6200-DA]
FHD
T240Hz
Edge LED
42” 70 W FPR : LC420EUH-KEF1 [42LM7600-DA]
47” 90 W FPR : LC470EUH-KEF1[47LM7600-DA]
55” 120 W FPR : LC550EUH-KEF1[55LM7600-DA]
