LG LM6210 Series Service Manual

- 15 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4.5.4.3. 3D model _XvYcc model (LM7600, 65LM6200)
** Analog(RGB): 128bytes
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 16 01 03 68 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
40 45 00 A0 5A 00 00 00 1E 66 21 50 B0 51 00 1B 30
50 40 70 36 00 A0 5A 00 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 00 5C
** HDMI 1 : 256Bytes
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 16 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 45 40 71 40 81 80
30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
40 45 00 A0 5A 00 00 00 1E 66 21 50 B0 51 00 1B 30
50 40 70 36 00 A0 5A 00 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 43
80 02 03 37 F1 4E 10 9F 04 13 05 14 03 02 12 20 21
90 22 15 01 26 15 07 50 09 57 07 78 03 0C 00 10 00
A0 B8 2D 20 C0 0E 01 4F 3F FC 08 10 18 10 06 10 16
B0 10 28 10 E3 05 03 01 02 3A 80 18 71 38 2D 40 58
C0 2C 45 00 A0 5A 00 00 00 1E 01 1D 80 18 71 1C 16
D0 20 58 2C 25 00 A0 5A 00 00 00 9E 01 1D 00 72 51
E0 D0 1E 20 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00
F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 11
** HDMI 2 : 256Bytes
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 16 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 45 40 71 40 81 80
30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
40 45 00 A0 5A 00 00 00 1E 66 21 50 B0 51 00 1B 30
50 40 70 36 00 A0 5A 00 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 43
80 02 03 37 F1 4E 10 9F 04 13 05 14 03 02 12 20 21
90 22 15 01 26 15 07 50 09 57 07 78 03 0C 00 20 00
A0 B8 2D 20 C0 0E 01 4F 3F FC 08 10 18 10 06 10 16
B0 10 28 10 E3 05 03 01 02 3A 80 18 71 38 2D 40 58
C0 2C 45 00 A0 5A 00 00 00 1E 01 1D 80 18 71 1C 16
D0 20 58 2C 25 00 A0 5A 00 00 00 9E 01 1D 00 72 51
E0 D0 1E 20 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00
F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 01
** HDMI 3 : 256Bytes
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 16 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 45 40 71 40 81 80
30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
40 45 00 A0 5A 00 00 00 1E 66 21 50 B0 51 00 1B 30
50 40 70 36 00 A0 5A 00 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 43
80 02 03 37 F1 4E 10 9F 04 13 05 14 03 02 12 20 21
90 22 15 01 26 15 07 50 09 57 07 78 03 0C 00 30 00
A0 B8 2D 20 C0 0E 01 4F 3F FC 08 10 18 10 06 10 16
B0 10 28 10 E3 05 03 01 02 3A 80 18 71 38 2D 40 58
C0 2C 45 00 A0 5A 00 00 00 1E 01 1D 80 18 71 1C 16
D0 20 58 2C 25 00 A0 5A 00 00 00 9E 01 1D 00 72 51
E0 D0 1E 20 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00
F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F1
** HDMI 3 : 256Bytes
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 16 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 45 40 71 40 81 80
30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C
40 45 00 A0 5A 00 00 00 1E 66 21 50 B0 51 00 1B 30
50 40 70 36 00 A0 5A 00 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 43
80 02 03 37 F1 4E 10 9F 04 13 05 14 03 02 12 20 21
90 22 15 01 26 15 07 50 09 57 07 78 03 0C 00 40 00
A0 B8 2D 20 C0 0E 01 4F 3F FC 08 10 18 10 06 10 16
B0 10 28 10 E3 05 03 01 02 3A 80 18 71 38 2D 40 58
C0 2C 45 00 A0 5A 00 00 00 1E 01 1D 80 18 71 1C 16
D0 20 58 2C 25 00 A0 5A 00 00 00 9E 01 1D 00 72 51
E0 D0 1E 20 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00
F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 E1
(Bold character)Checksum: Changeable by total EDID data.
EDID C/S data
8bit FHD
HDMI RGB
check sum (Hex) Block 0 0x43 RGB
Block 1 0x11 (HDMI1) 0x5C
0x01 (HDMI2)
0xF1 (HDMI3)
0xE1 (HDMI4)
