MAINTENANCE
OVEN LIGHT REPLACEMENT
1. Unplug the oven or turn off power at the main
power supply and wear gloves.
2.
Remove the vent cover mounting screws.
(2 outside screws)
3. Tip the cover forward, then lift out to remove.
4.
Remove the cover screw,pull the cover
forward and then lift up the bulb holder.
5. Replace the bulb with a 30 watt appliance bulb.
6.
Replace the bulb holder and screw.
7. Slide the top of the vent cover into place. Push
the bottom until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply.
COOKTOP/NIGHT LIGHT
REPLACEMENT
3. Replace the bulb with a 30 watt appliance bulb.
4. Replace the bulb cover and mounting screws.
5. Turn the power back on at the main power supply.
2. Remove the bulb cover mounting screws.
1. Unplug the oven or turn off power at the
main power supply.
7.
Slide the bottom of the vent cover into place. Push
the top until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply and set the clock.
6. Slide a new charcoal filter into place and close the
door. The filter should rest at the angle shown.
4. Open the door.
5.
Remove the old filter.
- 27 -
