LG LMVH1750SB Service Manual

1-1
SPECIFICATIONS
Rated Power Consumption ................................Microwave 1600W
Convection 1700W
Microwave Output ...............................................Microwave 950W (IEC60705)
Adjustable 95W through 950W, 10 steps
Convection 1500W
Frequency ..........................................................2450 MHz ±50 MHz
Power Supply .....................................................120 VAC, 60 Hz
Rated Current ....................................................Microwave 13.5A
Convection 14.0A
Magnetron Cooling .............................................Forced Air Cooling
Rectification .......................................................Rectification Voltage Double Half-Wave
Door Sealing ......................................................Choke System
Safety Devices ...................................................Magnetron Thermostat: Open at 150 °C ± 5 °C
Close at 0 °C ± 5 °C
............................................................................Oven Thermostat: Open at 145 °C ± 5 °C
Close at 0 °C ± 5 °C
............................................................................Fuse(20A)
............................................................................Primary Interlock Switch
............................................................................Secondary Interlock Switch
............................................................................Interlock Monitor Switch
Magnetron ..........................................................2M246
Cook top Lamp ...................................................130 V, 35 W
Cavity Lamp .......................................................130 V, 35 W
Timer ..................................................................Digital, up to 99 min. 99 sec. (in each cooking stage)
Tray ....................................................................Tempered Safety Glass
Overall Dimensions ............................................29
15
/16”(W)x16
7
/16”(H)x15
3
/8”(D)
Oven Cavity Size ...............................................21
1
/4”(W)x9
7
/16”(H)x14
3
/16”(D)
Effective Capacity of Oven Cavity ......................1.7 Cu.ft.
Accessories ........................................................Use & Care Guide, Cooking Guide, Installation Manual
Exhaust Adapter, Exhaust Damper, Mounting Kit & Two Filter
Shaft, Rotating Ring, Glass Tray, Grill Rack, Metal Tray
SWITCH CHART
SWITCH MODE
CONDITIONS
DOOR OPEN
OPEN OPEN CLOSE
CLOSE CLOSE OPEN
DOOR CLOSED
PRIMARY
INTERLOCK
SWITCH
SECONDARY
INTERLOCK
SWITCH
INTERLOCK
MONITOR
SWITCH
COM
NO
COM
NO
COM
NC
NOTE: Use the above switch chart with circuit diagram on page 5-1.
