10
INSTALLATION
INSTALLATION
Installation Overview
Please read the following installation instructions rst after purchasing this product or transporting it to another
location.
Check and choose the
proper location
Install anti-tip device Level the range Connect electric range
Conduit
connection
plate
Black White Red
Terminal
block
Plug in the power cord Engage the anti-tip device Test run
240 V
Product Specifications
The appearance and specications listed in this manual may vary due to constant product improvements.
Oven Range Models LREL6325* LREL6323* LREL6321*
Electrical requirements 120/240 V: 12.9 kW, 120/208 V: 9.7 kW
120/240 V: 13.1 kW,
120/208 V: 9.8 kW
Description Electric Single Oven Range
Exterior Dimensions
29
7
/
8
" (W) x 46
1
/
2
" (H) x 26
1
/
2
" (D) (D with door closed and excluding door handle)
75.9 cm (W) x 118.1 cm (H) x 67.4 cm (D)
(D with door closed and excluding door handle)
Height to cooking surface 36" (91.4 cm)
Total capacity 6.3 cu.ft.
