LG LS-J0762YL/NM/NN/NQ User Manual

-7-
Dimensions
(1) Indoor Unit
Tubing hole cover
D
H
W
Installation plate
Tubing hole cover
Installation plate
Right rear piping
Left rear piping
ø70mm
ø70mm
50mm
20mm
20mm
80mm
ø70mm
A
A
A
A
Center
Right rear pipingLeft rear piping
Center
ø70mm
MODEL
DIM Unit
W mm 820 888 824 900
H mm 262 287 260 285
D mm 165 170 165 156
7k, 9k Btu Series(AC) 12k Btu Series(AC) 9k Btu Series(DC) 12k Btu Series(DC)
(7k, 9k, 12k)
( 7k, 9k ) ( 12k )
( 7k, 9k ) ( 12k )
