72 | PERFORMANCE DATA
Single Zone Mega, Standard E󰀩ciency, and Mega 115V Wall Mounted Engineering Manual
EQUIPMENT SELECTION PROCEDURE
Correction Factors
Cooling / Heating Correction Factors
For Single Zone Mega, Standard Efficiency, and Mega 115V Wall Mounted systems, calculate the equivalent length of the liquid line from the
outdoor unit to the indoor unit. Also, determine the elevation difference of the indoor unit above or below the outdoor unit. Find corresponding
cooling or heating capacity correction factors as shown below. Multiply the correction factors by the cooling or heating capacity obtained from
the capacity tables using design conditions. The resultant is the NET cooling or heating capacity.
Cooling and Heating Capacity Coefficient Factors�
Table 46: Mega, Standard Efciency Cooling and Heating Capacity Coefcient Factors.
Operation
Mode
Piping Length (ft.)
16.4 24.6 32.8 49.2 65.6 82.0 98.4 114.8 131.2 147.6 164.0
Rate of
Capacity
Change (%)
LS090HEV2,
LS120HEV2,
LS090HFV3,
LS120HFV3
Cooling 100 100 97.7 93.0 - - - - - - -
Heating 100 100 98.3 95.0 - - - - - - -
LS180HEV2,
LS240HEV2,
LS180HFV3,
LS240HFV3
Cooling 100 100 99.0 97.0 95.0 - - - - - -
Heating 100 100 99.2 97.6 96.0 - - - - - -
Equivalent Piping Length for Piping Components
Component Size (Inches)
Elbow (ft.)
1/4 3/8 1/2 5/8 3/4 7/8 1 1-1/8 1-1/4 1-3/8 1-1/2 1-5/8 1-3/4 2-1/8
0.5 0.6 0.7 0.8 1.2 1.3 1.5 1.6 1.8 2.0 2.1 2.3 2.5 2.8
Table 47: Mega 115V Cooling and Heating Capacity Coefcient Factors.
Altitude Correction Factor
The impact of air density must be considered on systems installed at a significant altitude above sea level, therefore, locally accepted
altitude correction factors using ASHRAE guidelines must be applied.
Table 48: Equivalent Piping Length for Elbows.
Operation
Mode
Piping Length (ft.)
16.4 24.6 32.8 49.2 65.6 82.0 98.4 114.8 131.2 147.6 164.0
Rate of
Capacity
Change (%)
LS090HXV2
LS120HXV2
Cooling 100 100 97.7 93.0 - - - - - - -
Heating 100 100 98.3 95.0 - - - - - - -
