LG LS090HFV3 User Manual

PRODUCT DATA | 13
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Nominal
Tons
Unit Model
No.
Hertz Voltage
Voltage Range
(Min. to Max.)
MCA MOP
Compressor
Quantity
Compressor Motor
RLA
Outdoor Fan Motor Indoor Fan Motor
Cooling Heating W FLA W FLA
3/4 LS090HEV2
60 208 - 230 187-253
10.0 15 1 7.0 7.0 43 0.4 30 0.4
1 LS120HEV2 10.0 15 1 7.0 7.0 43 0.4 30 0.4
1-1/2 LS180HEV2 15.0 20 1 10.0 10.0 85 0.4 58 0.4
2 LS240HEV2 15.0 20 1 10.0 10.0 85 0.4 58 0.4
3/4 LS090HFV3 10.0 15 1 7.0 7.0 43 0.4 30 0.4
1 LS120HFV3 10.0 15 1 7.0 7.0 43 0.4 30 0.4
1-1/2 LS180HFV3 15.0 20 1 10.0 10.0 85 0.4 58 0.4
2 LS240HFV3 15.0 20 1 10.0 10.0 85 0.4 58 0.4
Mega, Standard E󰀩ciency, and Mega 115V Outdoor Units
ELECTRICAL DATA
Table 5: 208-230V, 60Hz, 1-Phase Single Zone Mega, Standard Efciency System Electrical Data Table.
Table 6: 115V, 60Hz, 1-Phase Single Zone Mega 115V System Electrical Data Table.
Nominal
Tons
Unit Model
No.
Hertz Voltage
Voltage Range
(Min. to Max.)
MCA MOP
Compressor
Quantity
Compressor Motor
RLA
Outdoor Fan Motor Indoor Fan Motor
Cooling Heating W FLA W FLA
3/4 LS090HXV2
60 115 98-132
15 25 1 11.0 11.0 43 0.4 30 0.4
1 LS120HXV2 15 25 1 11.0 11.0 43 0.4 30 0.4
Electrical Data for Mega, Standard Efficiency Models
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
Electrical Data for Mega 115V Models

LG LS090HFV3 Specifications
