INDOOR UNIT DIMENSIONS
LSN090HEV1
Ø 2-9/16
Ø 2-9/16
Right rear piping
Left rear piping
Installation Plate
Place a level on raised tab
Unit Outline
7- 9/16
14-7/8
29-3/4
7-1/4
10 -7/16
5
3
4
1
2
Unit: Inch
14-7/8
7- 9/16
Item No.
Part Name
2-15/16
5-11/16
Return Air Grille
Knockout Hole for Piping and Cables
1-3/4
2-3/16
2
2-3/8
5-5/8
2
2-1/8
2-3/8
2
1-3/4
