Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
REFRIGERANT PIPING CONNECTIONS
Single Zone Wall Mount Outdoor Unit Connections
(HSV3, HV3, HLV) - Continued
Outdoor Unit Connections
Figure 48: Pipe Attachment Figure 49: Outdoor Unit Piping Connection (HSV3)
Figure 50: Outdoor Unit Piping Connection (HV3, HLV)
Outdoor Unit
Gas Piping
(Larger diameter)
Liquid Piping
(Smaller diameter)
Torque Wrench
Bracket for
Main Power
Cables
HSV3
Outdoor Unit
Torque wrench
Liquid Piping
(Smaller diameter)
Gas Piping
(Larger diameter)
HV3, HLV
