29
ENGENGLISH
MAKING CONNECTIONS
Headphone connection
(Only 22/26/32/42CS47**)
Transmits the headphone signal from the TV to
an external device. Connect the external device
and the TV with the headphone as shown.
H/P
(*Not Provided)
NOTE
AUDIO menu items are disabled when
connecting a headphone.
Headphone impedance: 16 Ω
Max audio output of headphone: 9 mW to 15
mW
Headphone jack size: 0.35 cm
To Next Page
