LG LSC27931SB Service Manual

4. HOW TO DISASSEMBLE AND ASSEMBLE
1. REMOVING AND REPLACING
REFRIGERATOR DOORS
Before remove the doors, remove the Base Grille.
To remove the right (refrigerator) door:
CAUTION: When lifting the hinge free of the latch,
be careful that the door does not fall forward.
(1)
(2)
(3
)
(4)
(5)
1. Open the door. Remove the top hinge cover screw
3. Rotate the hinge lever (3) clockwise . Lift the top hinge
2. Use a flat blade screwdriver to pry back the hooks
(not shown) on the cabinet underside of the cover (2).
Lift up the cover.
4. Lift the door from the lower hinge pin.
5. Place the door, inside facing up, on a nonscratching
surface.
(1).
Type 2
Type 1
(4) free of the hinge lever latch (5).
(3
)
(4)
(5)
Rivet
NOTE: Regardless the type of hinge lever (3);
type1: without rivet or type 2: with rivet the
removal process is the same.
Removing the left (freezer) door with water line
connection.
•
(Figure 1) as shown in the figure below.
If a tube end is deformed or abraded, trim the
part away. Disconnecting the tube under the door
causes about 0.5 liters water to flow out. Put a large
container at end of tube to prevent water from draining
onto the floor.
Pull up the water feed tube while pressing area
• NOTE:
Figure 1
1. Open the door. Remove the top hinge cover screw (1).
2. Use a flat blade screwdriver to pry back the hooks
(not shown) on the cabinet underside of the cover (2).
Lift up the cover.
3. Disconnect all the wire harnesses (3).
4. Remove the grounding screw (4).
5. Rotate hinge lever (5) counterclockwise . Lift the top
CAUTION: When lifting the hinge free of the latch,
be careful that the door does not fall forward.
7. Place the door, inside facing up, on a nonscratching
surface.
6. being careful to Lift the door from the lower hinge pin
pull the water lines through the lower hinge pin.
hinge (6) free of the hinge lever latch (7).
(1)
(2)
(3)
(5)
(6)
(7)
(4)
Type 2
Type 1
(6)
(5)
Rivet
NOTE: Regardless the type of hinge lever (5);
type1: without rivet or type 2: with rivet the
removal process is the same.
(7)
- 9 -
