20 | PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
OUTDOOR UNIT DIMENSIONS
LSU181HSV3, LSU240HSV3, LSU307HV3, LSU360HV3
34-1/4
21-1/2
12-5/8
14-3/16
6-5/16
2-3/16
13-1/8
12-5/8
31-1/2
30-13/16
15-3/8
3-1/8
2
Ø20-7/8
ksrameRema
N t
raP.oN metI
1 Return Air Grille
2
3
4
5
6
Unit: inch
