LG LSU121HSV3 - INDOOR UNIT DIMENSIONS

22 | PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
INDOOR UNIT DIMENSIONS
LSN091HSV3, LSN121HSV3
Ø2-3/4
5-3/16
3-11/16
Right rear piping
Left rear piping
Installation Plate
Place a level on raised tab
Unit Outline
8-1/2
6-29/32
7-13/321
8-1/4
3
34-13/16
8-1/4
11-1/4
2
1
4
2-5/16
6-5/16
5
29/32
Unit: inch
Ø2-3/4
7-13/321
Return Air Grille
