16 Air Conditioner
Operating Instructions
The Horizontal Vane can be adjusted by using the remote controller.
1. Press the ON/OFF BUTTON to start the unit.
2. Press the vertical airflow direction button.
Each time the button is pressed, the air-flow
direction is changed in the direction of the arrow.
The Vertical Louvers can be adjusted by using the remote controller.
1. Press the ON/OFF BUTTON to start the unit.
2. Press the horizontal airflow direction button. Each time the button is pressed, the
airflow direction is changed in the direction of the arrow.
STOP
1 Step 2 Step 3 Step 4 Step 5 Step 6 Step Auto Swing
Horizontal Vane Control
Vertical Louver Control
※
Press the Vertical Airflow Direction button once more during Auto Swing at the direction of airflow you want.
※
Press the Horizontal Airflow Direction button once more during Full Auto Swing at the direction of airflow you want.
1 Step 2 Step 3 Step 4 Step 5 Step
Left Auto Swing Right Auto Swing
Full Auto Swing
STOP
•
Manually moving the Horizontal Vane or Vertical Louvers by hand could damage the mechanism.When the
unit is shut off, the the Horizontal Vane and Vertical Louvers will close the air outlet vent of the product.
• Air Conditioner memorizes the last operated angle.
So there is possibility of difference in the angle of Remote Controller and the unit after reoperation.
In that case, angle can be adjusted by pressing the Vane Control Button on the Remote Controller.
