7
ENGLISH
b. After aligning the wall bracket on the wall where the center of the wood stud is marked, mark the location of the
screws and then remove the wall bracket.
c. Use a level to make sure your screw marks are level.
d. Use the 4mm drill bit for wood to drill holes with the depth of 76mm or above where the wall mount screw location
is marked on the wall.
e. Clean the drilled hole.
f. Tighten the wall mount screws for the wall bracket on the drilled hole.
→ At this time, tighten the screw so that the wall, wall bracket and the wall mount screw are pressed against one
another. (Drywall can be damaged when tightened with excessive force, please be careful.)
→ When tightening the screw use the "+" driver (Manual or motorized) or 8mm wrench.
406mm
drywall
76mm
drywall
wood stud
a. Locate and mark the centers of the wall studs
using a stud finder.
<When mounting to wooden studs>
To Next Page
