LG LSXC22396S - Condenser Fan Error

Troubleshooting
8. Condenser Fan Error (E CF)
Symptom Check Point
1.- E CF 1. Check the air flow
2. Check the fan motor and connector
2. Check the PCB Fan motor voltage
Fan Motor
( P/N EBR809775**)
CON8
TEST MODE 1 Voltage [V]
CON8
11
th
pin ~ 16
th
pin
10~12 VDC
CON8
11
th
pin ~ 20
th
pin
2~4.5 VDC
CON8
11
th
pin ~ 14
th
pin
Not 0V, 5V
54
CON 6
CON 5
CON 2CON 3
CON 8
CON 7
CON 201
CON 1
