LG LSXC22396S - Page 61

2. Crush mode doesn’t work
Symptom Check Point
1. Crush mode
doesn’t work
1. Check the loose connection
2. Check the resistance
Auger MotorIce MakerDuct Motor
( P/N EBR809775**)
62
CON 6
CON 5
CON 2CON 3
CON 8
CON 7
CON 201
CON 1
