2. Crush mode doesn’t work
4
Check the resistance value.
Is Dispenser Motor resistance
9.9 ~ 12.1
No
Yes
Replace
Geared Motor
Resistance [Ω]
Dispenser Motor 9.9 ~ 12.1
Dispenser Motor
5
Check the voltage.
(while pushing the lever S/W)
Is voltage correct compared with
No
Yes
Change the
PCB
CON3
INSPECTION
POINT
LEVER S/W RESULT
Auger Motor (
CON3
4
th
pin ~ 7
th
pin
Pushing 112~115V
Not
Pushing
0~2V
4
Check the resistance value.
Is Auger Motor resistance
23~27
No
Yes
Replace
Geared Motor
Geared Motor Resistance [Ω]
Black / White
Harness
23~27
6
Explain to customer
2
Check the voltage.
(while pushing the lever S/W)
Is voltage correct compared with
No
Yes
1
Check the loose connection
3
Check the voltage .
Is Duct Motor voltage correct
No
Yes
Duct Motor Voltage [V]
Duct Motor
CON6
23
th
pin ~ 24
th
pin
Pushing 9~12V
Not
Pushing
0~2V
INSPECTION POINT
LEVER
S/W
RESULT
ICE/Water Lever SW
CON6
19
th
pin ~ 20
th
pin
Pushing 0~2V
Not
Pushing
3.5~5V
Change the
PCB
Change the
PCB
Crush mode doesn't work
Auger Motor
CON6
CON6
64
