LG LSXC22396S - Page 71

Poor cooling in Fresh food section
1
Check the sensor resistance.
8
Explain to customer
2
Reset the unit and
Input Test1 Mode
(Push the button 1 time)
3
Open the fresh food door and
Check the air flow D amper?
No
Yes
Check the
dampe
r
Go to 5
4
Check the air temperature.
Is it cold?
No
Yes
Check the
Compressor
and sealed
system
Go to 8
CON6 R1SNR
5
th
pin ~ 6
th
pin
Resistance [Ω]
23ºF /-5ºC 38k
32ºF / 0ºC 30k
41ºF / 5ºC 24k
50ºF / 10ºC 19.5k
59ºF / 15ºC 16k
CON7
TEST MODE 1 Voltage [V]
CON8
9
th
pin ~ 19
th
pin
2~4.5 VDC
5
Check the Fan Motor voltage
Is Fan Motor voltage 10~12V?
Yes
Replace
Main PCB
No
TEST MODE 1 Voltage [V]
CON8
9
th
pin ~ 12
th
pin
10~12 VDC
6
Check the Fan Motor voltage
Is Fan PWM voltage 2~4.5V ?
No
Replace
Main PCB
No
CON8
CON8
TEST MODE 1 Voltage [V]
CON8
9
th
pin ~ 10
th
pin
Not 0V, 5V
7
Check the Fan Motor voltage
Is Fan Feed Back voltage 0V,5V ?
No
Change the
motor
Yes
CON8
72
